Coupling Siam Thailand
Bao Tin Steel is an importer and distributor of Couplings, internal threaded connections. Customers wishing to buy mantles contact us for a quote with the best price.
Is a product of SIAM Fittings with full international certifications such as: FM Approved, UL Certificate, ISO 9001: 2008, PSB Certificate, IAPMO. SIAM Fittings currently manufactures two lines of fittings with working pressure Class 150 lbs and Class 300 lbs, including black and galvanized. Customers wishing to buy products or want to receive a quote for threading in Siam can contact Bao Tin Steel to receive information as quickly as possible.
Specifications of threaded sleeve, threaded connection in Siam
The following are the specifications and thread connections in Siam that customers can refer to first. Customers can contact Bao Tin Steel for direct advice on the product that customers are in need of buying.
STANDARD SPECIFICATIONS MALLEABLE IRON PIPE FITTINGS
| American 150lbs/300lbs | British 150lbs | Din 150lbs | |
Mateial – Tensile Strength – Elongation Demension – Fitting Dimension – Union Dimension 1. Union Brass Seat 2. Union Iron to Iron – Plug & Bushing Dimension Threads Zinc Coating Working Pressure | ASTM A197/A197M Min. 40,000 psi. (28.4 Kgf/mm²) Min. 5%
ASME B16.3
ASME B16.39 N/A ASME B16.14 ASME B 1.20.1 ASTM A153/A153M 150psi – 350 °F/ 300psi – 550 °F | Equivalent to EN1562 EN-GJMB-300-6
ASME B16.3
ASME B16.39
ASME B16.14 ISO 7-1 (Rc, R) Sec 5.3 BS 143 & 1256 150psi – 350 °F | Equivalent to EN1562 EN-GJMB-300-6
ASME B16.3
ASME B16.39 EN 10242 ASME B16.14 ISO 7-1 (Rp, R) Sec 5.2 En10242 150psi – 350 °F |
All threaded fittings are strictly tested before shipment. Therefore, customers who buy threaded sleeves and internal thread connections can be assured of product quality.
